Amplifier Features
|
|---|
| Amp Type |
Solid-State Preamp & Class D Power Amp |
| Chassis Material |
Aluminum |
| Preamp Tubes |
N/A |
| Power Amp Power Devices |
Class D Power Amp |
| Wattage(s) Quick Reference |
800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms |
| Power Amp Details |
Light-Weight, Compact Class D Power Amp with Protection & Limit LED Indicators |
| Convection or Fan Cooling |
Fan Cooled |
| Instrument Input Options |
1x 1/4" with Active/Passive Switch |
| Preamp Details |
Solid-State Preamp featuring Input Gain with Clip Indicator (O/D LED), Variable Voicing (Flat to Vintage Scoop), Fully Active 4-Band EQ (+/- 12dB of Bass, Low-Mid, High-Mid, Treble) plus Deep Switch (for enhanced low-end) and Master Volume |
| Effects Loop |
N/A |
| Solo Level Control |
N/A |
| Direct Line Output (DI) |
Balanced XLR Out with Pre/Post, Line/Mic & Ground Lift Switches |
| Tuner Output / Mute |
Play/Mute Switch (no tuner output) |
| External Switching Jack Options |
N/A |
| Speaker Outputs |
2 - Speakon Output Jacks (no 1/4" speaker jacks) - 8, 4 or 2 Ohms |
